Digital Display Low Load Brinell Hardness Tester

Model: 601XHB

Digital Display Low Load Brinell Hardness Tester

Application:

The 601XHB digital small load Brinell hardness tester is a high-tech product that integrates optics, electronics, and electronics. The instrument adopts a new high-resolution color touch screen, which displays intuitively and clearly, is easy to operate, and has adjustable backlight and energy-saving mode. Equipped with 8 levels of testing power, the Brinell scale can be freely selected from 9 types of tests; Equipped with two sets of objective lenses, 5 × and 10 ×, both of which can participate in measurement; Automatic switching between objective lens and pressure head; Pre-set test force holding time and adjust the strength of the measuring light source; The dual light source design of halogen lamp and LED ensures clear field of view for various sample surfaces; Visually display measurement scale, indentation length, hardness value, conversion scale, etc. on the touch screen; Real time saving of hardness test results, data classification, optional deletion, and printing output, automatic calculation of maximum, minimum, and average values; And equipped with an RS232 interface for users to connect to a computer for output. Optional CCD image automatic measurement system.

Comply to the testing standard: ISO6506, ASTM E10, JIS Z2243.


Features

1.Measurement of Brinell hardness under small load test force

2.Digital micrometer eyepiece, easy to measure

3.Dual objective automatic turret, with the objective lens constantly changing to measure different sizes of indentation.


Specification:

Description

Technical   parameters

Test force

1Kgf (9.8N),5Kgf (49.03N) 6.25Kgf (61.29N), 10Kgf (98.07N), 15.625Kgf (153.2N), 30Kgf   (294.2N), 31.25Kgf (306.5N), 62.5Kgf (612.9N)

Hardness   value

3.18-653HBW

Hardness   value resolution

0.1HBW

Data output

Built in printer, RS232 interface

Test force   application method

automatic loading, holding and unloading   test force

Hardness   reading

Color   touch screen, data can be stored

Objective   lens and indenter switching

Automatic

Exchange   Scales

HRA, HRBW, HRC, HRD, HREW, HRFW,   HRGW, HRKW, HBW, HV, HK, HS, HR15N, HR30N, HR45N, HR15TW, HR30TW,   HR45TW, HBS

Measuring   microscope magnification

50×100×

Dwell time   of test force

060s (input   arbitrarily as needed)

Eyepiece

10 x digital micrometer eyepiece

Objective

10×

Minimum   detection unit per grid

1μm

Maximum   height of specimen

185mm

Distance   from the center of the indenter to the outer wall

130mm

Dimension   and weight

530*240*630mm   ,35kgs

Power supply

AC220V/50Hz
